A7090 Brushless Low Profile Metal Gear HV Servo
P-SPMSA7090
Spektrum Spektrum 0605482153826
SRP: £79.99
SMAP:
Trade:

Barcode:
0605482153826

Features

  • High Voltage (HV) capable (4.8-8.4v input range)
  • Low profile design to fit into tighter spaces and shallow wing pockets
  • Impressive torque and speed in a standard low profile servo size (18kg-cm and .068 sec/60° @8.4v)
  • Durable and long-lasting brushless motor
  • Low wear and tightly meshed all metal gear train
  • Dual bearing supported drive train helps maximize smooth operation
  • Over Current and Temperature protection
  • Integrated servo failsafe holds last known position if signal is lost and power is maintained
  • Operating Frequency: 200hz to 333hz

A7090 High Torque High Speed Brushless Low Profile MG HV Servo

The low profile Spektrum A7090 brushless digital metal gear servo offers superb performance at a great price for standard aircraft applications. High voltage capable, the A7090 can produce an impressive 18 kg-cm (250 oz-in) of torque at blazing fast 0.068 sec/60° speeds with 8.4V input. Its low-wear, metal gear drive train is powered by a durable, long-lasting brushless motor and is supported by dual ball bearings for smooth operation. It also features low deadband and precise holding power. Like all Spektrum servos, the A7090 delivers reliability, consistency and performance that are second to none.




Support

Related Items

Optional Parts

Image Item Id Name Trade SSP Order
Now
  P-HAN9160 Aluminum Servo Arm, 2 (JR/SPM) £10.99
  P-SPMA3001 Heavy-Duty Servo Extension 6 £8.99
  P-SPMA3003 Heavy-Duty Servo Extension 12 £9.99
  P-SPMA3004 Heavy-Duty Servo Extension 18 £9.99
  P-SPMA3005 Heavy-Duty Servo Extension 24 £10.99
  P-SPMA3006 Heavy-Duty Servo Extension 36 £11.99
  P-SPMA3052 Standard Servo Extension 9 £11.99
  P-SPMA3058 Standard Y-Harness £19.99
  P-SPMA4042 Socket Head Servo Mounting Screws (20) £4.50
  P-SPMXBC100 XBC100 Smart Battery Checker & Servo Tester £59.99
  Y-SPMA3054 Servo Connector Clips (25) £5.99
  Y-SPMSP3035 Hardware Set: A6300 £15.99
  Z-AR390196 Female To Male JR 150mm Servo Extension £6.99
