. . . TLR 1/10 22X-4 ELITE 4WD Buggy Race Kit

  • New
  • TLR
  • 1/10th 22X-4 Elite 4WD Race Kit
  • ETA: May 2022

PRODUCT OVERVIEW

Even though the 22X-4 won the ROAR Nationals, the next generation is hot on its heels. The Team Losi Racing 22X-4 Elite Race Kit has everything that made the 22X-4 a podium pleaser and more. The Elite level kit includes popular option parts like a centre diff, aluminium drag link, carbon fibre electronic mounting plates, carbon wing washer, aluminium locknuts, and titanium turnbuckles to lighten and optimize the 22X-4 to maximize performance. Designed to win straight out of the box, the 22X-4 ELITE Race Kit is tough to beat with features and performance destined for the top of the podium.
FEATURES
  • Pro Level Ready
  • Aluminium Option Parts Included
  • Geometry Updates
  • Tab Style Battery Mount
  • Centre Diff Fan Mount
  • Titanium Turnbuckles
  • G3 V2 3mm Shaft Shocks
  • Adjustable Inner Pivots
  • V2 Floating Servo Mount
  • Optimized Composites
  • Adjustable Motor and Battery Position
  • 22X-4 Lightweight Body
  • Carbon Fibre Optimized
  • All Metric Hardware
  • TLR 6.5" Rear Wing
  • Easy Access Diffs


22X-4 Lightweight Body

Sleek, stylish, and lightweight, the 22X-4 body design is the perfect match to the chassis. It looks sleek and fast, is nice and low but provides excellent balance and stability - the best of all worlds.


G3 V2 3mm Shaft Shocks

The G3 V2 shocks give the 22X-4 the plush handling and consistent, leak-free bleed with some ease of use improvements. No more e-clips as the pistons are now secured by screws, new shock caps and shock bodies increase the spring collar height by 3mm to accommodate lower ride heights, new eyelets and spring cups provide -3mm, 0mm and +4mm spring cup off-sets and paired with all new eyelets will never pop off with the screw in feature.


Adjustable Inner Pivots

Included for the front and rear, the adjustable inner pivots give multiple adjustments for anti-squat, kick up, toe, sweep, pivot width, and roll centre. This gives the 22X-4 ELITE the windows needed to get it dialed in for any driver, any track and any surface.


Centre Diff Included

The most popular tuning option for the 22X-4 has been the change to a centre diff, especially for dirt and clay tracks. So of course, the 22X-4 ELITE would not be truly ELITE without the centre diff included.


Pro Level Ready

Including all of the key option parts that our factory team uses to win races across the world, the 22X-4 ELITE is truly Pro Level Ready from a kit build right out of the box... more so than any 4wd buggy kit ever offered. Parts include Carbon Fiber, Black Anodized Aluminium and Titanium turnbuckles. The option parts and upgrades included value at £100.


Optimized Composites

The balance and consistency of the 22X-4 ELITE can be tuned using different composite materials in key parts throughout the vehicle. The kit included the parts the race team prefers: Standard front and rear suspension arms, soft mudguards, and standard chassis braces.


Geometry Updates

The 22X-4 was an all-new car, and after racing it around the world for the last couple years, we've found ways to make it even better. Additional shock mounting locations, inner camber link locations, smoother ackermann and steering gain locations all just keep getting the 22X-4 ELITE easier and easier to drive faster and faster.


Titanium Turnbuckles

Titanium turnbuckles have always been a premium upgrade for race vehicles, and we just couldn't do the 22X-4 ELITE without them. Included are titanium turnbuckles throughout the buggy to save weight and increase performance.


Aluminium Option Parts Included

As the team has found many of the optional aluminium parts for the 22X-4 to improve maintenance or performance, we've included those in the kit as well. Aluminum parts included are the drag link, caster blocks, all four inner pivots, motor mount, front and rear hexes, ball stud washers, and aluminium nuts throughout.


Tab Style Battery Mount

Keeping the battery in while you're running, and getting it out easy when it's time to charge is just something we thought we could do better. Carbon tabs hold the battery down, with adjustable height to accommodate any battery, thin or standard height. Easy in, secure while running, easy out, done.
Image Item Id Name Trade SSP Order
Now
  C-TLR03026 1/10 22X-4 ELITE 4WD Buggy Race Kit £599.99
IN THE BOX
  • (1) TLR 1/10 22X-4 Elite Race Buggy Kit (includes optional extras)
  • (1) Product Manual

NEEDED TO COMPLETE
  • (1) Transmitter and Receiver
  • (1) Steering Servo
  • (1) 2S LiPo or LiHV Battery
  • (1) Compatible Battery Charger
  • (1) 48P Pinion Gear
  • (1) Motor + Fan (Optional)
  • (1) ESC
  • (1) Tyre Glue
  • (4) Tyres
  • Polycarbonate Paint
  • Tools (Please reference the manual for more details)
