. . . Arrma TLR Tuned Typhon 1/8 Race Buggy 4WD Roller

Product Overview

Loaded with high-end parts for improved strength, handling, and long-term durability, the 1/8 scale ARRMA® TLR® Tuned TYPHON 4WD Race Buggy Roller provides bashers with the perfect platform for entering competitive racing and experimenting with their chassis to achieve the best performance.

The large number of TLR® Tuned parts and factory-finished body with bold racing colour scheme immediately set this model apart from its ready-to-run TYPHON 6S BLX 4WD Speed Buggy brother. The TLR® Tuned TYPHON 4WD Race Buggy Roller is the ultimate ARRMA® 1/8 scale buggy straight out of the box, primed and ready to hit the racetrack - and still tough enough to handle off-road bashing. Just add your choice of 4S or 6S brushless power system and the TLR® Tuned TYPHON will blast over rough terrain with ease.

The durable TLR® Tuned aluminium upgrades include the chassis plate, steering rack, adjustable upper and lower suspension hangers, shock bodies, and front and rear shock towers. All are laser-etched with the TLR® Tuned logo. The chassis also features strong composite side pods and front and rear braces. The oil-filled, adjustable shocks have machined tapered pistons and Extreme Bash stand-offs.


The TLR® Tuned TYPHON 4WD Race Buggy Roller also features a heavy-duty drivetrain that holds up to extreme bashing, with all-metal diff outdrives and gearbox internals plus durable steel driveshafts throughout. Its extra-strong wheel hubs support low-drag wheels on which ARRMA® engineers have mounted multi-terrain, race compound dBoots® Exabyte tyres for next-level grip. A Race Spec tunable rear wing helps to keep the tyres and buggy grounded, contributing to confident control and responsive handling at high speeds.

Maintenance downtime is kept to the minimum with an efficient, driver-friendly design. For example, an aluminium sliding mount gives you fast, hassle-free access to your motor.

The 1/8 scale TLR® Tuned TYPHON 4WD Race Buggy Roller is the ultimate ARRMA® buggy. For intermediate-level bashers interested in racing, it offers top-of-the-line durability and tuning capabilities to give you a successful head start.




Product Features
  • TLR Tuned 7075-T6 Laser-Etched Aluminium Chassis Plate
  • TLR Tuned 7075-T6 Laser-Etched Aluminium Front and Rear Shock Towers
  • TLR Tuned 7075-T6 Laser-Etched Aluminium Steering Rack
  • TLR Tuned Laser-Etched Aluminium Lower Adjustable Suspension Hangers
  • TLR Tuned Laser-Etched Aluminium Upper Adjustable Suspension Hangers
  • TLR Tuned Laser-Etched Aluminium Shock bodies
  • Strong front and rear composite chassis braces
  • Strong composite chassis side pods
  • Rear suspension dirt guards
  • Oil-filled adjustable shocks
  • Machined tapered shock pistons
  • EXB Extreme Bash shock stand-offs
  • Heavy-duty drivetrain
  • All-metal diff outdrives and gearbox internals
  • Durable steel driveshafts throughout
  • Galvanized turnbuckles
  • X-Hard servo saver spring
  • Black anodized aluminium easy-access sliding motor mount
  • Black aluminium servo mount
  • Race Spec high rear wing mount
  • Race Spec tunable rear wing
  • Factory-finished Race Spec body colours and decals
  • dBoots Exabyte race compound tyres
  • Low-drag 1/8 buggy wheels
  • Aluminium 17mm wheel hex




TLR Tuned Parts

The TLR Tuned TYPHON 4WD Race Buggy Roller has been upgraded with high-end aluminium parts that increase durability and improve handling. For intermediate-level bashers, it's the perfect platform to use for racing and to gain experience with tuning - Designed Fast and Designed Tough!


Oil Filled Shocks

The adjustable oil-filled shocks are mounted on TLR Tuned 7075-T6 Aluminium Shock Towers and feature TLR Tuned Aluminium Shock bodies, machined tapered shock pistons, and EXB Extreme Bash shock stand-offs. They easily soak-up bumps over dirt, asphalt, and grass for super-smooth damping.




The suspension hangers have also received the TLR Tuned treatment. These aluminium hangers are anodized and laser etched in the TLR Tuned style. The suspension hangers use adjustment blocks that allow you to tune the geometry of the suspension to maximize the performance of your buggy.


The chassis plate has machined in pockets where material has been strategically removed to reduce weight without sacrificing strength.


A Race Spec tunable rear wing helps to keep the tyres and buggy grounded, contributing to confident control and responsive handling at high speeds. The wing is tunable using 5mm or 10mm Gurney flaps that can be mounted to the rear edge. These alter the downforce that is created by the wing.




High Traction dBoots Exabyte Tyres

The dBoots Exabyte tyres are made of high-quality, race compound rubber for long-lasting durability and feature a multi-surface tread pattern for excellent traction in all conditions. They include foam inserts and are pre-glued to low-drag, 1/8 buggy nylon wheels. The 17mm hex fitting provides strength during extreme action and allows easy maintenance.


Race Spec Finished Body

Topping off the TLR Tuned TYPHON 4WD Race Buggy Roller is a sleek, factory-finished body featuring exclusive Race Spec colours and decals. A low-drag, tunable rear wing helps keep the buggy grounded, contributing to confident control and responsive handling at thrilling high speeds.




The front hub nuts, 17mm aluminium wheel hexes and steering plates have also received black anodizing.


TLR Tuned steering rack features multiple mounting positions for the steering links. This allows you to tune the level of Ackermann in the steering system.


The TLR Tuned front lower aluminium suspension mounts use adjustment blocks to tune the suspension arm geometry. These allow the front kick-up, width and roll center of the front lower arms to be adjusted.




Image Item Id Name Trade SSP Order
Now
  C-ARA8306 TLR Tuned TYPHON 1/8 4WD Roller (Pink/Purple) £459.99

What's in the Box?
  • (1) ARRMA TLR Tuned TYPHON 1/8 Race Buggy 4WD Roller
  • (1) Product Manual


Needed to Complete
  • ESC, Motor and Pinion
  • Transmitter and Receiver
  • Steering Servo
  • Batteries (1x4S or 2x2S)
  • Compatible Charger
  • LiPo Charging Bag

Completion Items
Image Item Id Name Trade SSP Order
Now
  P-SPM5200 DX5 Rugged 5Ch DSMR Tx w/SR515 £229.99
  P-SPM5025 DX5 Pro 2021 DSMR TX w/SR2100 £374.99
  P-SPM2340 DX3 3Ch DSMR Radio w/SR315 £99.99
  P-SPMSS6260 S6260 High Torque High Speed Digi HV Servo-Metal Gear £109.99
  P-SPMSS6280 S6280 Standard Digital HV Ultra Torque High Speed Waterproof £149.99
  P-SPMXSE1150 Firma 150 Amp Brushless Smart ESC £169.99
  M-SPMXSM1600 FIRMA 1900KV BRUSHLESS MOTOR £119.99
  M-SPMXSM1700 FIRMA 2050KV BRUSHLESS MOTOR £109.99
  P-CC010-0145-00 Mamba Monster X £199.99
  P-CC010-0145-05 Monster X 25.2V ESC, 8A BEC W/1512-1800kV Sensored £319.99
  Z-LOSA3574 1.0 Module Pitch Pinion, 14T: 8E,SCTE £13.99
  Z-AR310475 Steel Pinion Gear 14T Mod1 5mm £13.99
  O-SPMXPS4I Spektrum Smart PowerStage Bundle 2 x 2S 5000mAh IC5 £269.99
  O-SPMXC2010I S2200 Smart G2 AC Charger 2x200W £249.99
  O-SPMXC2040I S1400 Smart G2 AC Charger 1x400W £229.99
  O-SPMXC1010I Spektrum Smart S2100 AC Charger, 2x100W £169.99
  O-GAC1003E-UK IMars III Charger 2~6S/3~18NiMH 100W AC £49.99
  O-GC4H6000-130G5 Li-Po HV Car Hard Case 4S 15.2V 6000mAh 130C RL with 5mm £119.99
  O-GC4H6550-120G5 Li-Po HV Car Hard Case 4S 15.2V 6550mAh 120C with 5mm £119.99
  O-GC4S6750-70X9 Li-Po Car Hard Case 4S 14.8V 6750mAh 70C with XT90 £99.99
  O-GC4S5500-50X9 Li-Po Car Hard Case 4S 14.8V 5500mAh 50C with XT90 £79.99
  O-DYN1405 LiPo Charge Protection Bag, Large £22.50
  O-FS-LCB02 Li-Po Battery Bag - Charge Bag 23x30cm £6.99
